● Linux OS.

● Supports RS485.

● 1024 x 600 Resolution.

● 7” Capacitive touch screen.

● Dimensions: 216.4 x 118.8 x 21.7 mm.

Accessories

• S562 Desktop Stand
• S562 On-Wall Mounting Stand
• S562 Surface Mount Angle
• S562 Desktop Bracket

  ________________________________________________________

  Physical & Power

  • Front panel: Plastic
  • RAM/ ROM:128MB / 128MB
  • Display: 7 Inch TFT LCD 1024×600 resolution
  • Screen: 7 lnch capacitive touch screen
  • RS485 port: Support
  • Relay out: 1
  • Bell in: 1
  • l/0: 8
  • Microphone: -42dB
  • Speaker: 4Ω /2w
  • Ethernet ports: 2xRJ45, 10/10OMbps adaptive
  • 802.3af Power-over-Ethernet
  • 12V DC connector (if not using PoE)
  • Installation: Wall-mounted & Desktop
  • Dimension: 216.4×118.8×21 . 7mm
  • Working Humidity: 10~90%
  • Working Temperature: -10°C~ +45°C
  • Storage Temperature: -20°C~ +70°C
