Amplify the moment with an Apollo™ marine amplifier – designed specifically for use with your Fusion® DSP-enabled marine stereo and Fusion speakers. This powerful and efficient 6 channel amplifier is the difference between hearing the music and feeling it. With an impressive 150-watt RMS per channel (at 4 ohm), this amplifier can power up to six pairs of speakers or four pairs of speakers and one subwoofer. The Easy Tune feature automatically regulates audio settings for the best sound quality without manual adjustments (Requires setup using the Fusion-Link™ app on a compatible smartphone).
Features :
Impressive Power : 150-watt RMS per channel (at 4 ohm), capable of powering up to six pairs of speakers or four pairs of speakers and one subwoofer.
Easy Installation : Proprietary cable connectors and a mounting bracket is included in the box. The cable connectors allow you to pre-wire your speakers/subwoofers, while the mounting bracket allow you to simply clip the amplifier in place for a clean finish.
High Power Mode : High-power mode adapters are included in the box, designed to simplify the way you bridge two channels in high power mode, increasing the output power.
Physical Dimensions Without Bracket (WxHxD) : 11.69″ x 7.06″ x 1.75″ (297 x 180 x 45 mm)
Physical Dimensions With Bracket (WxHxD) : 11.69″ x 7.06″ x 2.13″ (297 x 180 x 50 mm)
Weight : 5.95 lb (2.7 kg)
Water Rating : IPX2
Amplifier Class : Class-D
CEA-2006 Power Rating : 150-watt RMS x 6 @ 14.4 V input – 4 ohm < 1% THD
Total Rated Power Output – 2 ohm (watt) : 290-watt RMS x 6 @ 14.4 V input – 2 ohm < 1% THD
Total Rated Power Output – 4 ohm Bridged (watt) : 580-watt RMS x 3 @ 14.4 V input – 4 ohm Bridged < 1% THD
Peak Power (watt) : 1800-watt
Input Sensitivity : 1.3 V RMS
Input Impedance : 22k ohm
Operating Voltage : 10.8 V – 16 V DC
Current Consumption (StandBy) : < 5 mA @ 14.4 V input
Current Consumption (Idle) : < 1.32 A @ 14.4 V input
Current Consumption (Max) : 78 A
Fuse Rating : 125 A electronic fuse (no replacement necessary)
